Awning & Casement Window Repair Sydney

Learn more about our robust window repair solutions.

Residential Series | Series 516

Australians can’t get enough of the amazing value and performance of the Vantage® Residential Series aluminium awning windows.

  • Opens out from the bottom for great ventilation and protection from unexpected showers.
  • 50mm aluminium frame.
  • Perfect for single or double glazing.
  • A huge variety of performance-glass options to maximise energy efficiency.
  • Can be supplied with a chain winder.
  • Casement type sash option available. These sashes are fitted with stainless steel friction stays and wedgeless cam handle

Maximum Panel Height Various
Maximum Panel Width Various
Maximum Panel Width ≤ 20mm
SHGC Range 0.21 – 0.66
Uw Range 3.4 – 6.6

✓ Acoustics Testing Certified
✓ AS2047 Testing Certified
✓ BAL40 Testing Certified
✓ Safe4Kids Testing Certified

  WERS Rating

Awning/Casement Windows

Sash
Standard and heavy duty sash options.

Awning/Casement Windows

Fly Screens
Designed to accept screen when used with chainwinder.

Awning/Casement Windows

Glazing
Will accept single or double glazing up to 20mm IGUs.

Awning/Casement Windows

Winders
Colour matched, key operated chainwinders.

Residential Series | Series 517


Maximum Panel Height Various
Maximum Panel Width Various
Maximum Panel Width ≤ 20mm
SHGC Range 0.27 – 0.66
Uw Range 3.8 – 7.1

✓ Acoustics Testing Certified
✓ AS2047 Testing Certified
✓ BAL40 Testing Certified
✓ Safe4Kids Testing Certified

  WERS Rating

Awning/Casement Windows

Sash
Standard and heavy duty sash options.

Awning/Casement Windows

Winders
Colour matched, key operated chainwinders.

Designer Series | Series 616

Perfect for cooler climates, the bold, architectural style of our Vantage® MAGNUM™ Awning windows and casements can’t be matched!

  • Airtight to keep out the cold.
  • A great choice if you want to leave the windows open but stay protected from passing showers.
  • Bold frame that allows for extra wide sashes.
  •  A range of glass options, including double glazing.
  • Windows can be fixed if you prefer.
  • The option for integrated flyscreens, chain winders, Truth™ scissor winders or casement latches.

Maximum Panel Height Various
Maximum Panel Width Various
Maximum Panel Width ≤ 24mm
SHGC Range 0.14 – 0.56
Uw Range 4.1 – 6.9

✓ Acoustics Testing Certified
✓ AS2047 Testing Certified
✓ BAL40 Testing Certified
✓ Safe4Kids Testing Certified

  WERS Rating

Awning/Casement Windows

Sill Option
Condensation drainage sill option.

Awning/Casement Windows

Winder Options
Concelaed electric chainwider with integrated screen.

Awning/Casement Windows

Trims and Adaptors
Full range of sill types and trims to suit your application.

Awning/Casement Windows

Bold Sash Design
Stronger bolder sash than standard residential.

Awning/Casement Windows

Replacement Trims
Series 616 will accept snap on replacement trims for a finished look on retrofits.

Designer Series ThermalHEART™ | Series 726

These awning and casement windows from our Vantage® ThermalHEART™ range are the ultimate choice to boost your home’s comfort and energy efficiency.

  • Choose top-hinged awning sashes or side-hinged casement sashes.
  • Perfect for architecturally designed homes.
  • Clean, bold frames incorporate a thermal insulation strip to minimise the transfer of heat and cold.
  • Sashes seal tightly against the frame for greater energy efficiency.
  • Used in conjunction with double glazing, they’re up to 33% more efficient than standard double-glazed windows.
  • The option of integrated flyscreens that nest neatly into the frame – no more ugly rivets or unsightly screws.
  • Your choice of manual or electric hardware.

Maximum Panel Height Various
Maximum Panel Width Various
Maximum Panel Width ≤ 32mm
SHGC Range 0.13 – 0.47
Uw Range 2.7 – 5.5

✓ Acoustics Testing Certified
✓ AS2047 Testing Certified
✓ BAL40 Testing Certified
✓ Safe4Kids Testing Certified

  WERS Rating

Awning/Casement Windows

Thermal Break
Incorporates multiple thermal breaks to minimise transfer of heat.

Awning/Casement Windows

Colour Options
Available in a range of single or dual colour options.

Awning/Casement Windows

Glazing
Will accept single or double glazing up to 32mm IGU.

Awning/Casement Windows

Winder Options
Manual chainwinders can be fitted with integrated flyscreens.

Residential Series | Series 504

If you want maximum ventilation and views, the Vantage® Residential Series aluminium sliding window is the ideal choice.

  • Designed to carry large expanses of glass and 24mm thick double-glazing, these elegant, architectural awning and casement windows can withstand the harshest of environments and keep you safe from the elements.
  • Awning sashes can be fitted with cam handles, manual chain winders or concealed electric winders.
  • Awning and casement designs both accept handy flyscreens for year-round protection from creepy crawlies.
  • These frames are easily installed into brick veneer and cavity brick building designs. So convenient!
  • Cleverly designed to allow for internal or external glazing – a great feature if the windows are hard to reach.

Maximum Panel Height Various
Maximum Panel Width Various
Maximum Panel Width ≤ 24mm
SHGC Range 0.14 – 0.57
Uw Range 4.2 – 7

✓ Acoustics Testing Certified
✓ AS2047 Testing Certified
✓ BAL40 Testing Certified
✓ Safe4Kids Testing Certified

  WERS Rating

Architectural Series | Series 467

High performance windows for secure and convenient operation in any Australian environment.

  • These high-performance CentreGLAZE awning and casement windows are designed to accept Truth™ Hardware for large installations. It’s all about giving you the security you demand along with ease of operation. In fact, the scissor-type winders require 50% less effort to operate than conventional chain winders and can be combined with stile latches to provide additional locking points for even more strength and security.
  • Extra-strong window sashes carry large glass spans to maximise your available view without compromising on strength or performance.
  • They’ve also been successfully tested to 450Pa water resistance so they’re ideal for any Australian environment.
  • Fixed sidelights/lowlights and highlights can be single or double glazed for better energy performance and comfort.
  • Installation into brick veneer and cavity brick has been made easier with built-in nailing fins (weather bars) in the perimeter frame.

Maximum Panel Height Various
Maximum Panel Width Various
Maximum Panel Width ≤ 24mm
SHGC Range 0.14 – 0.57
Uw Range 4.2 – 7

✓ Acoustics Testing Certified
✓ AS2047 Testing Certified

  WERS Rating

Residential Series | Series 755

The ComfortEDGE™ Awning Window from the Vantage® Residential Series delivers a highly energy efficient window using embedded technology. This significantly minimises exposed aluminium and drastically reduces heat transfer in and out of the building.

Ideal for residential applications using standard aluminium framing.

  • Excellent weather performance (600pa) makes it suitable for use in exposed locations throughout Australia
  • Patented technology using a fully embedded frame
  • Excellent energy performance
  • Incredible insulation of your home
  • Single and double reveal options
  • 75mm framing accepts up to 20mm Insulated Glazing Units
  • Revolutionary in performance, styling and affordability

Maximum Panel Height Various
Maximum Panel Width Various
Maximum Panel Width ≤ 20mm
SHGC Range 0.224 – 0.572
Uw Range 2.32 – 3.22

✓ AS2047 Testing Certified

  WERS Rating

Awning/Casement Windows

75mm Frame
75mm Frame accepts 18-20mm IGU’s for optimal energy performance and increased frame strength.

Awning/Casement Windows

Integrated Awning Sill
Integrating the frame with the reveal delivers a minimalist design aesthetic and optimal viewing plane to the outdoors.

Awning/Casement Windows

Excellent Thermal Performance
Thermal performance is achieved by reducing the exposed internal boundary and the ability to transfer energy through the aluminium frame.

Awning/Casement Windows

Easily Accepts Screens
Fly-screen clips hold fly-screens neatly against the frame and allow for easy installation and removal.

Awning/Casement Windows

Colour Match Fly Screen
Colour match fly screen to your internal finishes for a discreet appearance.
